The Ultra Fine Silver Coated Copper Stranded Wire 7*0.03mm features 7 strands of 0.03mm copper wire, coated with a 0.2µm to 0.5µm silver layer. Made from oxygen-free copper (OFC), it offers excellent conductivity and durability. With a diameter range of 0.01mm to 0.05mm, it is ideal for high-precision applications in robotics and medical devices. Its tensile strength of 160-200 N/mm² ensures strong, stable performance.
| Parameter | Stranded Wire |
| Conductor Type | Stranded (7/19/37 strands) |
| Diameter | 0.01-0.05mm |
| Conductor Material | Copper (OFC) |
| Silver Coating Thickness | 0.2μm-0.5μm |
| Tensile Strength | 160-200 N/mm² |
| Key Applications | Robotics/Medical divice |
Superior Conductivity: Made from oxygen-free copper (OFC), this wire ensures excellent electrical conductivity for efficient energy transmission.
Enhanced Durability: The silver coating (0.2µm to 0.5µm) improves resistance to oxidation and corrosion, ensuring a longer lifespan in harsh environments.
High Precision: With a fine diameter range of 0.01mm to 0.05mm, it is ideal for delicate and high-precision applications such as robotics and medical devices.
Strong Mechanical Performance: The wire’s tensile strength of 160-200 N/mm² provides robust mechanical properties, ensuring stability and reliability even under stress.
Versatility: Suitable for various advanced applications in electronics, robotics, and medical technology, where high-performance materials are crucial.
