We offer high - performance Solar Cable and Copper Core Cable for photovoltaic power generation. These cables are engineered to meet the rigorous demands of solar energy systems, ensuring efficient and reliable power transmission.
Models: H1Z2Z2 - K and PV1 - F
H1Z2Z2 - K: Rated voltage AC: 0.6/1kV; DC: 1.5kV, conductor cross - section 2.5 - 240mm². It's a copper core cross - linked polyolefin insulated solar photovoltaic cable, complying with prEN 50618: 2014.
PV1 - F: Rated voltage AC: 0.6/1kV; DC: 1.8kV, conductor cross - section 2.5 - 35mm², meeting 2 Pfg 1169/08.2007 standard.
General Standards: Our copper core cables can also be produced according to UL 4703 standard, with performance fully meeting the requirements.
Models: PV/LH - F, AAPV1 - F, PV1500V - DC
Standards: Comply with 2PFG 2642/11.17, and performance meets Tü2PFG 2642/11.17 or EN50618 standard.
Connection between solar cell modules.
Connection between the battery and the inverter.
Connection between the battery array and the controller or the DC junction box.
Equivalent to aluminum alloy photovoltaic cables in some performance aspects, ensuring reliable power transmission for solar systems.
Have different current - carrying capacities based on conductor cross - section and installation method (exposure to air, laying on surface, surface connection). For example, a 2.5mm² copper core cable has a current - carrying capacity of 41A when exposed to air (PV1 - F/H1Z272 - K series).
Temperature deviation conversion factor adjusts current - carrying capacity with ambient temperature. For instance, at 70℃, the conversion factor is 0.91, reducing the effective current - carrying capacity.
Long service life (≥25 years) and high cost - performance.
Wide temperature range: Ambient temperature - 40℃ - 90℃, maximum operating temperature of conductor 125℃, maximum operating ambient temperature of cable 90℃, and allowable short - circuit temperature 250℃ within 5S.
Minimum bending radius is 6 times of the cable diameter, facilitating installation.
Also have current - carrying capacities varying with conductor cross - section and installation method. For example, a 4mm² aluminum alloy cable has a current - carrying capacity of 43A when a single core is exposed to air.
Model | Rated voltage | Conductor cross section | Name | Standard number |
H1Z2Z2-K | AC:0.6/1kV; DC:1.5kV | 2.5-240mm² | Copper core cross-linked polyolefin insulated solar photovoltaic cable | prEN 50618: 2014 |
PV1-F | AC:0.6/1kV DC:1.8kV | 2.5-35mm² | 2 Pfg 1169/08.2007 |
Section（mm²） | (Tinned copper) Type of conductor | Insulation thickness | Approximate outer diameter | 90°C Min Insulation Resistance MQ.km | 20°C Max Conductor Resistance (Q2/km) | ||
PV1-F | H1Z272-K | PV1-F | H1Z272-K | ||||
2.5 | 5 | 0.6 | 0.7 | 5.5 | 5.9 | 0.69 | 8.21 |
4 | 5 | 0.6 | 0.7 | 6.2 | 6.6 | 0.58 | 5.09 |
6 | 5 | 0.6 | 0.7 | 6.8 | 7.2 | 0.5 | 3.39 |
10 | 5 | 0.7 | 0.8 | 7.9 | 8.3 | 0.42 | 1.95 |
16 | 5 | 0.7 | 0.8 | 9.2 | 9.6 | 0.34 | 1.24 |
25 | 5 | 0.7 | 1.0 | 11.2 | 11.7 | 0.34 | 0.795 |
35 | 5 | 0.7 | 1.0 | 12.2 | 13.6 | 0.29 | 0.565 |
Nominal section（mm²） | Installation method(A) | ||
Exposure to the air | Laying on the surface | Surface connection | |
1.5 | 30 | 29 | 24 |
2.5 | 41 | 39 | 33 |
4 | 55 | 52 | 44 |
6 | 70 | 67 | 57 |
Nominal section（mm²） | Installation method(A) | ||
Exposure to the air | Laying on the surface | Surface connection | |
10 | 98 | 93 | 79 |
16 | 132 | 125 | 107 |
25 | 176 | 167 | 142 |
35 | 218 | 207 | 176 |
Ambient temperature （℃） | Below 60 | 70 | 80 | 90 | 100 | 110 |
Conversion factor | 1.00 | 0.91 | 0.82 | 0.71 | 0.58 | 0.41 |
| Model | Name | Application condition | |
| PV/LH-F | Aluminum alloy core solar photovoltaic cable | AA:0.6/1KV DC:below 1.8KV | |
| AAPV1-F | |||
| PV1500V-DC | |||
| Section mm² | Insulation thickness （mm） | Approxima outside diameter （mm） | Reference weight（kg/km） | Maximum resistance at 20 ℃ (Ω/km) |
| 1.5 | 0.7 | 4.5 | 27 | 19.9 |
| 2.5 | 0.7 | 5.0 | 34 | 11.9 |
| 4 | 0.7 | 6.0 | 42 | 7.45 |
| 6 | 0.7 | 6.2 | 52 | 4.96 |
| 10 | 0.8 | 8.3 | 87 | 2.98 |
| 16 | 0.8 | 9.4 | 112 | 1.86 |
| 25 | 1.0 | 11.7 | 172 | 1.19 |
| 35 | 1.0 | 13.6 | 220 | 0.827 |
| 50 | 1.2 | 16.0 | 310 | 0.579 |
| 70 | 1.2 | 18.1 | 413 | 0.413 |
| 95 | 1.4 | 20.4 | 542 | 0.331 |
| 120 | 1.4 | 22.3 | 644 | 0.248 |
| 150 | 1.6 | 25.5 | 730 | 0.199 |
| 185 | 1.6 | 28.0 | 895 | 0.156 |
| 240 | 1.8 | 31.7 | 1015 | 0.124 |
| Nominal section mm² | Installation method | ||
| Single core cable exposed to the air | Single core cable laid on the surface | single core cable which surface connected | |
| 1.5 | 24 | 23 | 19 |
| 2.5 | 32 | 32 | 26 |
| 4 | 43 | 41 | 35 |
| 6 | 55 | 53 | 45 |
| 10 | 77 | 73 | 62 |
| 16 | 104 | 99 | 85 |
| 25 | 139 | 132 | 112 |
| 35 | 172 | 164 | 139 |
| 50 | 225 | 214 | 182 |
| 70 | 261 | 248 | 211 |
| 95 | 336 | 319 | 272 |
| 120 | 407 | 387 | 330 |
| 150 | 462 | 439 | 374 |
| 185 | 514 | 488 | 416 |
| 240 | 616 | 585 | 499 |
| Ambient temperature（℃） | Below 60 | 70.0 | 80 | 90 | 100 | 110 | |
| Conversion factor | 1.00 | 0.91 | 0.82 | 0.71 | 0.58 | 0.41 | |
